Product Category
R410A Split
UKK model
| Model | 9000btu | 12000btu | 18000btu | 24000btu | |||
| Power supply | Ph-V-Hz | 220v50hz, 220v/60hz | 220v50hz, 220v/60hz | 220v50hz, 220v/60hz | 220v50hz, 220v/60hz | ||
| Cooling | Capacity | W | 2500 | 3200 | 5300 | 7100 | |
| Input | W | 870 | 1120 | 1810 | 2200 | ||
| Rated current | A | 4.0 | 5.1 | 8 | 9.6 | ||
| Heating | Capacity | W | 2750 | 3600 | 5800 | 7500 | |
| Input | W | 760 | 1020 | 1950 | 2500 | ||
| Rated current | A | 3.5 | 4.7 | 8.7 | 10 | ||
| Compressor | Type | ¡¡ | Hitachi | Toshiba | Toshiba | Hitachi | |
| Indoor unit | Indoor air flow (Hi/Mi/Lo) | m3/h | 450/400/320 | 500/450/380 | 850/700/650 | 1100/980/880 | |
| Noise level(Hi/Mi/Lo) | dB(A) | 39/37/34 | 40/37/34 | 43/40/37 | 50/46/43 | ||
| Unit dimension (W*H*D) | mm | 800*290*196 | 800x290x196 | 860x292x205 | 1080x330x220 | ||
| Packing (W*H*D) | mm | 870*365*280 | 870X365X280 | 930X365X280 | 1180x425x300 | ||
| Net weight | Kg | 10 | 10 | 12 | 15 | ||
| Gross weight | Kg | 11.5 | 11.5 | 14 | 20 | ||
| Outunit unit | Unit dimension (W*H*D) | mm | 600x480x250 | 700x540x255 | 770x520x280 | 845x680x310 | |
| Packing (W*H*D) | mm | 725x575x350 | 800x620x375 | 910X620X380 | 1010x765x430 | ||
| Net weight | Kg | 26 | 30 | 41 | 59 | ||
| Gross weight | Kg | 29 | 33.5 | 44.5 | 64 | ||
| Refrigerant type | ¡¡ | R410A | R410A | R410A | R410A | ||
| Application area | m2 | 10~15 | 14~21 | 15-30 | 21~41 | ||
| Qty¡¯per 20¡¯& 40¡¯&40HQ | Set | 125/258/290 | 103/220/254 | 92/196/222 | 60/128/143 | ||
