Product Category
48000btn
UN Model
| Model | |||||
| Rated Capacity |
Cooling | W | 14000 | ||
| Heating | W | 14000 | |||
| Dehumidifying | Kg/h | 4.2 | |||
| Rated Power Consumption |
Cooling | W | 5850 | ||
| Heating | W | 5850 | |||
| Rated Running Current |
Cooling | A | 10.00 | ||
| Heating | A | 10.00 | |||
| Electricheating power Power | W | ||||
| Max. Input Power | W | 8850 | |||
| Max. Input Current | A | 14.5 | |||
| EER Cooling | W/W | 2.40 | |||
| COP Heating | W/W | 2.40 | |||
| Power supply source | V/Ph/Hz | 380-415~3/50Hz | |||
| Refrigerant | R410A | ||||
| Refrigerant Charged | g | 3300 | |||
| Max. Discharge Pressure | Mpa | 4.15 | |||
| Max. Suction Pressure | Mpa | 1.15 | |||
| Air Flow Volume | m3/h | 2100 | |||
| Noise level | dB£¨A) | 52 | |||
| Noise level | dB£¨A) | 62 | |||
| Indoor unit weight | Kg | 58 | |||
| Outdoor unit weight | Kg | 105 | |||
| Dimension |
Net Dimension | mm | 1255¡Á945¡Á340 | ||
| Packing Dimension | mm | 1300¡Á1085¡Á430 | |||
| Loading Quantity | sets | 18/36/48 | |||
